Description
The 702 S3 Signature takes our state-of-the-art flagship 700 Series floorstanding loudspeaker and evolves it to deliver unparalleled levels of performance.
Crafted. Honed. Perfected.
Engineered for pristine studio-quality sound at home, the 702 S3 Signature utilises upgraded midrange and low-frequency motor systems, improved capacitors, revised speaker terminals, plus a more open tweeter grille mesh, as developed for our 800 Series Signature loudspeakers.
Technical Details
-
Drive units 1x ø25mm (1 in) Decoupled Carbon Dome high-frequency
1x ø150mm (6 in) Continuum cone FST midrange
3x ø165mm (6.5 in) Aerofoil Profile bass
-
Frequency range -6dB 28Hz - 33kHz
-
Frequency response 46Hz - 28kHz ±3dB
-
Harmonic distortion 2nd and 3rd harmonics (90dB, 1m on axis)
<1% 86Hz - 28kHz
<0.5% 110Hz - 20kHz
-
Nominal impedance 8Ω (minimum 3.1Ω)
-
Recommended amplifier power 30W - 300W into 8Ω on unclipped programme
-
Sensitivity 90dB spl (2.83Vrms, 1m)
-
Technical features Decoupled Carbon Dome tweeter
Solid Body Tweeter-on-Top
Continuum™ cone FST™ midrange
Decoupled midrange
Aerofoil™ Profile bass cones
Flowport™
-
Description3-way vented-box system
-
Max recommended cable impedance 0.1 Ohm
Size & weight
-
Net weight39.5kg
-
Dimensions Height: 1010mm cabinet only
1138mm including tweeter and plinth
Width: 192mm cabinet only
290mm including plinth
Depth: 354mm cabinet only
391mm including grille and terminals
410mm including plinth
