McIntosh MSA5500 Integrated Amplifier w/Streamer

In stock

Regular price $16,495.00
Sale price $16,495.00 Regular price
-Liquid error (snippets/price line 111): divided by 0% off
Limited Time Offer

Not available online. Contact us for purchase options.

Customer Care & Support

In Store pickup

Free Delivery above $500 in AU

View full details

Description

MSA5500 2-Channel Streaming Integrated Amplifier

Ideal for Streaming Music with 2-Channel Audio Systems

  • Type: Solid State
  • 100 Watts x 2-Channels into 8 Ohms
  • 160 Watts x 2-Channels into 4 Ohms
  • Power Guard®, Sentry Monitor™, Monogrammed Heatsinks™, Solid Cinch™ speaker binding posts
  • 12 analog and digital inputs
  • Stream with Apple® AirPlay®, Bluetooth®, Google Cast™, Qobuz Connect, Spotify® Connect, and TIDAL® Connect
  • A certified Roon Ready and Roon Tested device

ALL-IN-ONE EFFORTLESS MUSIC STREAMING

The MSA5500 Streaming Integrated Amplifier is both a full featured music streamer and powerful integrated amplifier in one. It can serve as the cornerstone of your audio setup, whether it be your first venture into high-fidelity audio, an addition to your existing system, or to use at your office or vacation home. Crafted to perfection and compact in size, the MSA5500 is tailor-made for modern living spaces, making it an ideal choice for those seeking premium audio in more confined environments.

The versatile MSA5500 has a wide assortment of wireless music streaming capabilities plus a variety of physical inputs to connect source components. If all your music is cloud based digital music, a simple addition of speakers is all that's needed to be bathed in elevated sound quality.

ENDLESS STREAMING POSSIBILITIES AWAIT

The MSA5500 is compatible with a multitude of leading streaming technologies and platforms including Apple® AirPlay®; Bluetooth®; Google Cast™ (formerly Chromecast); Qobuz Connect; Spotify® Connect (including Spotify Lossless); and TIDAL® Connect (including TIDAL Max). No special control app or technical skills are needed; the easy-to-use MSA5500 invites you to simply stream your music directly from your smart device.1 If you've been using a lower quality wireless home sound system, then listening to your favorite tracks through the MSA5500 will be like hearing them again for the first time.

For Bluetooth streaming, the MSA5500 utilizes Bluetooth 5.0; the high bitrate Advanced Audio Coding (AAC) standard; Qualcomm® aptX HD for hi res audio playback; and Qualcomm aptX Adaptive, a robust solution that delivers high resolution, uninterrupted audio over Bluetooth. Two Wi-Fi 6 antennas and one Bluetooth antenna provide stable wireless connections, while an Ethernet port is also available for wired connections.

STREAMED MUSIC HAS NEVER SOUNDED SO GOOD

To elevate your auditory experience of your digital music, the MSA5500 employs an audiophile-grade digital-to-analog converter (DAC) to convert digital signals into the analog format needed for playback. This next generation, Quad Balanced, 8-channel, 32-bit DAC features huge dynamic range and low distortion. Regardless the file format, you can expect a transcendent audio experience with pristine sound reproduction.

The MSA5500 has received Roon Ready certification from Roon Labs, making it an endpoint device for use with the Roon music player. Roon brings all your music together and adds tons of data – bios, reviews, photos, lyrics, tour dates, and cross-linked credits for performers, songwriters, producers, engineers, and composers. Roon Ready network devices have Roon streaming technology built in and are certified by Roon to provide the highest level of quality and performance in network streaming. It has also received Roon Tested certification as Roon has profiled it to ensure simple setup and effortless daily use.

ALL THE CONNECTIONS YOU NEED

In addition to all its streaming capabilities, the MSA5500 also comes 7 digital and 5 analog audio inputs to connect audio components, such as a CD player or tuner, plus a Moving Magnet phono input to connect a turntable. The digital inputs support high resolution digital audio playback; the USB input supports native playback of DSD512 and DXD up to 384kHz, while the coax and optical inputs can decode digital music up to 24-bit/192kHz.

UNRIVALED TV SOUND

The inclusion of an HDMI (ARC) input lets you connect your compatible TV so you can enjoy your favorite shows and movies with a sound quality level that TV speakers or soundbars just can't provide.2 Popular multi-channel audio formats from Dolby® and DTS® will be expertly converted to two-channel audio for proper playback. The subwoofer output allows for a powered subwoofer to be added for extra punch so you can feel every bass and low-end note.

ACCOMODATES YOUR CHANGING NEEDS

As your audio needs evolve, the MSA5500 can grow with you. Someday you may move into a bigger space or add a larger set of speakers and find that you need more power. If that happens, you could bypass the internal amplifier and connect a bigger external amplifier – all while continuing to use the MSA5500's familiar streaming and preamplifier sections. You can rest assured that the MSA5500 can accommodate your changing needs and be a lifelong partner in your audio pursuits.

EMBRACE THE ICONIC MCINTOSH EXPERIENCE

Elegantly appointed with timeless McIntosh aesthetics, including blue Watt meters, a sleek black glass front panel with aluminum end caps, rotary control knobs, an illuminated logo, and impeccable build quality, the MSA5500 epitomizes audio sophistication.

Electronic Specifications

  • FTC Power Output Rating 100 W
  • Power Output per Channel 100 W into 8 ohms 160 W into 4 ohms
  • Number of Channels 2
  • Rated Power Band 20Hz to 20kHz
  • Total Harmonic Distortion 0.005%
  • Dynamic Headroom 1.8dB
  • Frequency Response +0,-0.5dB 20Hz to 20kHz
  • Frequency Response, +0, -3dB 10Hz to 100kHz
  • Sensitivity Phono (Moving Coil) N/A
  • Sensitivity Phono (Moving Magnet) 2.5mV
  • Sensitivity High Level (Balanced / Unbalanced) 0.5V/0.25V
  • Sensitivity (Power Amp input) 1V
  • Signal To Noise Ratio (Moving Coil) N/A
  • Signal To Noise Ratio (Moving Magnet) 82dB
  • Signal To Noise Ratio (High Level) 95dB
  • Signal To Noise Ratio (Power Amp input) 110dB
  • Input Impedance (Balanced / Unbalanced) 20K/20K
  • Damping Factor 8 ohms: >200 4 ohms: >100
  • Maximum Output (Balanced / Unbalanced) 8V Unbalanced

Connectivity

  • Balanced Input 1
  • Unbalanced Input 4
  • Phono Input Moving Coil 0
  • Phono Input Moving Magnet 1 (fixed loading)
  • Upgradeable Digital Audio Module No
  • Digital Coaxial Input 2
  • Digital Optical Input 2
  • Digital MCT Input 1
  • Digital USB Input 1
  • HDMI (ARC) Input 1
  • Balanced Variable Output 0
  • Unbalanced Fixed Output 0
  • Unbalanced Variable Output 1
  • Headphone Output 1/4" High Drive with Headphone Crossfeed Director (HXD®)
  • Subwoofer Output 1
  • AM/FM Tuner option No
  • Home Theater PassThru Yes
  • Unbalanced Analog Connector Type Standard
  • Speaker Binding Post Type Standard
  • Service Port 1

Digital Audio Specifications

  • Digital-to-Analog Converter (DAC) Type 8-channel, 32-bit/384kHz PCM/DSD, Quad Balanced
  • Digital Coaxial Input Sample Rate 24-bit/44.1kHz to 192kHz
  • Digital Optical Input Sample Rate 24-bit/44.1kHz to 192kHz
  • Digital MCT Input Sample Rate 16-bit/44.1kHz (CD) DSD64 (SACD)
  • Digital USB Input Sample Rate 32-bit/44.1kHz to 384kHz (PCM) DSD64, DSD128, DSD256, DXD352.8kHz, DXD384kHz
  • Digital Network/Wi-Fi Input Sample Rate 24-bit/44.1kHz to 192kHz

Control

  • Tone Controls Bass and Treble
  • Tone Bypass and Input Assign Yes
  • RS232 Control Input Yes
  • Power Control Output 1 Main
  • Rear Panel Data Port 2
  • Rear Panel IR Sensor Input Yes
  • Input Level Match Yes

General Specifications

  • Vacuum Tube or Solid State Solid State
  • Output Type Direct Coupled
  • Output Meters Yes
  • Dual Layer Chassis Yes
  • Chassis Finish Black painted steel
  • McIntosh Monogrammed Heatsinks™ Yes
  • Standby Power Requirement <0.25 Watts
    Power Requirement 230 Volts, 50/60Hz at 1.6 amps

Weights & Dimensions

  • Unit Dimensions (W x H x D) 17-1/2" (44.45cm) x 6" (15.2cm) (8-1/8” (20.6cm) with vertical antenna) x 18-3/4” (47.6cm) with vertical antenna (22-1/4" (56.5cm) with horizontal antenna)
  • Unit Weight 38 lbs (17.2 kg)
  • Shipping Weight 55.5 lbs (25.2 kg)
